powerCON TRUE1 kabeldeel 2p+PE bus IP65/IP66/IP67 kd= 8-13mm General Brand Neutrik Productcode NAC3F-TRUE1-CG Manufacturer's website GTIN Type powerCON TRUE1 Show all of this type Serie powerCON Show all in this series ETIM Class Circular connector (industrial connector) Show all in this class Net weight 0.030 kg GLN 7613187000003 Commodity code 85366990 Technical information Ordering information SKU CNTPC2201 MPN NAC3F-TRUE1-CG Orderable Stock item Delivery Time 1 day Decrease per piece(s) Order unit piece(s) Minimum / step size decrease 1 / 1 piece(s) Usage unit bag Dimensions 85. mm x 50. mm x 25. mm Weight 0.041 kg Pack quantity 50 piece(s) Gross price € 9.90 Net € 9,90 Discount group 2300 SKU CNTPC2202 MPN NAC3F-TRUE1-CG-D Orderable Stock item Delivery Time 1 day Decrease per piece(s) Order unit piece(s) Minimum / step size decrease 1 / 1 piece(s) Usage unit box BULK packed Dimensions 280. mm x 200. mm x 190. mm Weight 2.200 kg Pack quantity 4 piece(s) Gross price € 484.00 Net € 484,00 Discount group 2300B Hazardous substances and certificates REACH REACH Document Location Safety Information Safety Information Location Battery RoHS RoHS Document Location WEEE Waste Code DoC Location DOP Location CE marking CE Location ISO number DIN number ECCN number UN number Documents powerCON TRUE1 kabeldeel 2p+PE bus IP65/IP66/IP67 kd= 8-13mm Brand Neutrik Productcode NAC3F-TRUE1-CG The powerCON TRUE1 is a locking true mains connector for harsh and demanding applications. It replaces appliance couplers wherever a very rugged solution in combination with a locking device is needed in order to guarantee a safe power connection. The powerCON TRUE1 is a connector series with breaking capacity (CBC), i.e. it can be connected or disconnected under load or live. Features & Benefits Heavy duty sealed power connector for harsh and demanding environment Lockable single phase connector ENEC and VDE certified according to IEC 60320-1 and EN IEC 60320-1 IP65, IP66 and IP67 (mated) Easy and reliable twist lock system Uses high impact UV-resistant materials Extremely robust and reliable UL and CSA Certified According to UL 60320-1 and CSA 22.2 No. 60320-1 True mains connector with breaking capacity (CBC) Unique NEUTRIK locking bushing and strain relief for cable diameters 8 mm to 13 mm (0.31 – 0.51 inches) SKU CNTPC2201 MPN NAC3F-TRUE1-CG 146 Available: 1 day bag Add to cart Order per 1 piece(s) bag Pack quantity 50 Gross price € 9.90 Net € 9,90 Stock item 146 Available: 1 day Order before 3:00 PM? We’ll ship it the same working day! * powerCON TRUE1 kabeldeel 2p+PE bus IP65/IP66/IP67 kd= 8-13mm BULK50 Brand Neutrik Productcode NAC3F-TRUE1-CG The powerCON TRUE1 is a locking true mains connector for harsh and demanding applications. It replaces appliance couplers wherever a very rugged solution in combination with a locking device is needed in order to guarantee a safe power connection. The powerCON TRUE1 is a connector series with breaking capacity (CBC), i.e. it can be connected or disconnected under load or live. Features & Benefits Heavy duty sealed power connector for harsh and demanding environment Lockable single phase connector ENEC and VDE certified according to IEC 60320-1 and EN IEC 60320-1 IP65, IP66 and IP67 (mated) Easy and reliable twist lock system Uses high impact UV-resistant materials Extremely robust and reliable UL and CSA Certified According to UL 60320-1 and CSA 22.2 No. 60320-1 True mains connector with breaking capacity (CBC) Unique NEUTRIK locking bushing and strain relief for cable diameters 8 mm to 13 mm (0.31 – 0.51 inches) SKU CNTPC2202 MPN NAC3F-TRUE1-CG-D 3 Available: 1 day box BULK packed Add to cart Order per 50 piece(s) box BULK packed Pack quantity 4 Gross price € 484.00 Net € 484,00 Stock item 3 Available: 1 day Order before 3:00 PM? We’ll ship it the same working day! *
powerCON TRUE1 kabeldeel 2p+PE bus IP65/IP66/IP67 kd= 8-13mm Brand Neutrik Productcode NAC3F-TRUE1-CG The powerCON TRUE1 is a locking true mains connector for harsh and demanding applications. It replaces appliance couplers wherever a very rugged solution in combination with a locking device is needed in order to guarantee a safe power connection. The powerCON TRUE1 is a connector series with breaking capacity (CBC), i.e. it can be connected or disconnected under load or live. Features & Benefits Heavy duty sealed power connector for harsh and demanding environment Lockable single phase connector ENEC and VDE certified according to IEC 60320-1 and EN IEC 60320-1 IP65, IP66 and IP67 (mated) Easy and reliable twist lock system Uses high impact UV-resistant materials Extremely robust and reliable UL and CSA Certified According to UL 60320-1 and CSA 22.2 No. 60320-1 True mains connector with breaking capacity (CBC) Unique NEUTRIK locking bushing and strain relief for cable diameters 8 mm to 13 mm (0.31 – 0.51 inches) SKU CNTPC2201 MPN NAC3F-TRUE1-CG 146 Available: 1 day bag Add to cart Order per 1 piece(s) bag Pack quantity 50 Gross price € 9.90 Net € 9,90 Stock item 146 Available: 1 day Order before 3:00 PM? We’ll ship it the same working day! *
powerCON TRUE1 kabeldeel 2p+PE bus IP65/IP66/IP67 kd= 8-13mm BULK50 Brand Neutrik Productcode NAC3F-TRUE1-CG The powerCON TRUE1 is a locking true mains connector for harsh and demanding applications. It replaces appliance couplers wherever a very rugged solution in combination with a locking device is needed in order to guarantee a safe power connection. The powerCON TRUE1 is a connector series with breaking capacity (CBC), i.e. it can be connected or disconnected under load or live. Features & Benefits Heavy duty sealed power connector for harsh and demanding environment Lockable single phase connector ENEC and VDE certified according to IEC 60320-1 and EN IEC 60320-1 IP65, IP66 and IP67 (mated) Easy and reliable twist lock system Uses high impact UV-resistant materials Extremely robust and reliable UL and CSA Certified According to UL 60320-1 and CSA 22.2 No. 60320-1 True mains connector with breaking capacity (CBC) Unique NEUTRIK locking bushing and strain relief for cable diameters 8 mm to 13 mm (0.31 – 0.51 inches) SKU CNTPC2202 MPN NAC3F-TRUE1-CG-D 3 Available: 1 day box BULK packed Add to cart Order per 50 piece(s) box BULK packed Pack quantity 4 Gross price € 484.00 Net € 484,00 Stock item 3 Available: 1 day Order before 3:00 PM? We’ll ship it the same working day! *
